How do you perform a basic aluminum hull weld repair on a fishing boat in 2027?

Weld it yourself or pay a shop: the two real options compared

Every aluminum hull crack on a fishing boat ends up in one of two lanes, and the fork happens before you strike an arc. Lane one is the owner-performed repair: you buy or borrow a machine, prep the metal, run the bead, and eat the learning curve on your own transom. Lane two is the marine fabrication shop, where a certified welder does the same work with a bigger machine, a rotating fixture, and insurance behind the bead.

The owner-performed lane makes sense on hull plate thicker than about 0.100" (roughly 12 gauge, common on riveted johnboats and welded jon/skiff hulls in the 0.125"–0.190" range), on cracks under about 6" long, and on areas you can reach from both sides with the boat on a trailer or blocks. A 0.125" 5052 side panel with a 3" stress crack radiating from a rivet hole is the archetypal DIY job. So is a pinhole at a weeping seam, a torn-out bilge pump through-hull boss, or a split at the corner of a livewell. These are low-consequence welds: if the bead is ugly but sound, the boat floats and fishes.

The shop lane takes over when any of four things is true. First, thickness under 0.080" — thin transom skins, tiller-boat gunwale caps, and older 0.063" side panels burn through so fast that a hobbyist with a spool gun will chase a growing hole down the panel. Second, structural members: transom knees, stringers, the keel bar, motor-mount plate, and anything carrying outboard thrust. A failed transom weld under a 90-horse outboard is not an aesthetic problem. Third, unknown alloy or a hull that has been previously repaired with the wrong filler — mystery metal wants a shop that can test or at least recognize it. Fourth, castings: lower units, cleat bases, and cast fittings are a different metallurgical animal from rolled plate and crack again immediately if welded like sheet.

There is a genuine third option that people forget, and honesty about it saves money: not welding at all. For a hairline weep at a rivet line on an older riveted hull, a proper re-buck of the rivet plus a marine seam sealer often outlasts a weld, because welding a riveted hull dumps heat into a panel that was never designed as a welded assembly and frequently opens a new crack an inch away. Structural adhesives and mechanical patch plates with butyl bedding are legitimate field repairs for a crack you need to fish this weekend. They are not permanent, but "not permanent" for a 16-foot aluminum boat can still mean several seasons.

The trade-off is straightforward. DIY costs equipment and risk and buys you the ability to fix the next crack in an hour. The shop costs money and downtime and buys you a bead that will not be the reason the boat sinks. Most owners who fish hard end up doing both — DIY on the cosmetic and minor structural stuff, shop on anything that touches the transom.

Choosing your process: TIG, spool-gun MIG, or push-pull

Within the DIY lane there is a second fork that matters more than the first: which process you actually perform the repair with.

AC TIG is the accuracy king. On a 0.090"–0.125" hull you set AC balance around 65–70% electrode negative, frequency 120–200 Hz for a tight arc cone, and run roughly 1 amp per 0.001" of thickness as a starting point — about 100–130 amps for 0.125" plate, less with a pedal you actually modulate. TIG gives you total control over heat input, which is the whole ballgame on thin marine aluminum. It is also slow, requires two coordinated hands plus a foot, and is unforgiving of contamination. Realistically, a first-timer needs several hours of scrap practice before a TIG bead on a hull will hold water.

Spool-gun MIG is what most boat owners actually use. The spool gun puts the 0.030" or 0.035" soft aluminum wire two inches from the arc so it cannot birdnest in a long liner. It is fast, forgiving of a shaky hand, and deposits enough metal to fill a beveled crack in one or two passes. Typical settings on 0.125" hull plate land near 19–21 volts with wire speed in the 300–400 IPM neighborhood, but every machine's dial is different — burn a scrap coupon of the same thickness and tune until the arc sounds like tearing paper rather than popping. Argon at 25–30 CFH, straight argon, never a CO2 mix.

Push-pull guns are the shop answer: better feeding on long runs, but the gun alone costs more than most hobby machines and there is no reason to own one for occasional hull work.

What you cannot use: flux-core, stick with steel rod, and any "aluminum brazing rod" marketed as a no-weld miracle. Low-temperature aluminum brazing rods do have a narrow legitimate use — filling a pinhole in non-structural sheet where you cannot get a machine — but they create a dissimilar-metal joint that corrodes in salt water and they will not hold a stressed seam. Do not use them on a transom.

mermaid flowchart TD P1["Haul out, dry hull completely"] --> P2["Remove foam and fuel<br/>from the heat zone"] P2 --> P3["Strip paint 2 in each side<br/>both faces of the panel"] P3 --> P4["Degrease with acetone"] P4 --> P5["Stainless brush, aluminum-only<br/>one direction toward joint"] P5 --> P6["Degrease again"] P6 --> P7["Dye penetrant to find<br/>true crack ends"] P7 --> P8["Stop-drill 1/8 to 3/16 in<br/>at each end"] P8 --> P9{"Plate over 0.100 in?"} P9 -->|Yes| P10["Bevel V, 60-70 deg included"] P9 -->|No| P11["No bevel needed"] P10 --> P12["Clamp flat, backing bar behind seam"] P11 --> P12 P12 --> P13["Tack every 2 in, alternating"] P13 --> P14["Stitch weld 3/4 to 1 in<br/>cool between stitches"] P14 --> P15["Grind flush, blend edges"] P15 --> P16["Dye penetrant the finished bead"] P16 --> P17["Water or soap-and-air leak test"] P17 --> P18["Prime and paint, add anode if bare"] </parameter> </invoke>

Running the bead and sequencing the repair

With the prep done, the welding itself is the short part.

Start on scrap. Cut a coupon of the same thickness — ideally a cutoff from an access panel you removed — and dial the machine in on it. Burn through the coupon deliberately so you learn what burn-through looks and sounds like *before* you do it to the boat. This five-minute step is worth more than any amount of reading.

Position matters more on aluminum than on steel. Flat is dramatically easier because the puddle is fluid and gravity is not your friend overhead. If you can rotate the boat, block it, or lay it on its side to get the seam flat, do it. An hour spent repositioning the hull saves an hour of fighting a running puddle.

Direction of travel. With MIG, push the gun (forward-angled 10–15°), do not drag — pushing gives better gas coverage and a cleaner bead on aluminum, which is the opposite of the habit steel welders have. With TIG, keep the torch nearly vertical with a slight lead angle, add filler at the leading edge of the puddle, and keep the tungsten out of the puddle.

The stitch sequence. Do not run left to right. Use a back-step or skip sequence: weld an inch at one end, then an inch at the far end, then fill toward the middle, alternating. This distributes heat and prevents the panel from progressively warping in one direction. Pause between stitches and physically check panel temperature with the back of your hand a few inches away.

Cratering. Aluminum craters at the end of every stop and craters crack. Back up over the last 1/4" of the bead and taper off, or use the machine's crater fill/downslope function if it has one. On TIG, ramp the pedal down rather than lifting off.

Cap and cover. Once the root is filled, a light cover pass tied into both toes of the joint gives you a bead that will grind flush without leaving an undercut.

Grinding. Blend the bead, do not erase it. Grinding a weld flush to the panel and then some removes the very reinforcement you just added. On a hull you generally want the bead dressed to a slight crown outside, flush inside where it might interfere with a floor or a wire chase.

Sequencing after the arc goes out. First, dye-penetrant the finished bead — the same kit you used to find the crack ends will find porosity and cracks in the new weld. Second, leak-test: the simplest method is to fill the affected compartment or the hull interior with a few inches of water and watch the outside for weeping, or, for a sealed compartment, apply soapy water outside and gentle low-pressure air inside. Do not pressurize a hull compartment hard — a few PSI is plenty and more can deform a panel or blow a seam.

Corrosion protection. Bare aluminum at the repair is anodically active and, in salt water, will start pitting. Prime with a self-etching aluminum primer, then topcoat. Confirm your sacrificial anodes are present and not depleted — a fresh weld with a spent anode is a corrosion cell waiting to happen. If you welded near a stainless fitting, make sure any isolation washers or bedding compound that you disturbed get replaced.

Sea trial. Launch, run at planing speed, then re-inspect the bead and the surrounding panel. Vibration and hull flex find weld defects that a static water test does not. Check again after the first full day of fishing.

What goes wrong, and how to catch it early

Black soot and a wandering arc means contamination or wrong polarity/gas. Stop, re-clean, verify pure argon.

Porosity — a bead full of pinholes almost always traces to moisture, oil, or inadequate gas coverage. Check flow rate, check for a draft blowing the shield gas away (an open boat on a windy ramp is a terrible weld booth), and re-clean.

Burn-through means too much heat or too slow travel. On thin plate, raise the travel speed rather than cutting the amperage first — too little heat with slow travel gives you cold lap, which looks fine and holds nothing.

A crack that reappears a few inches from the repair is the diagnostic that matters most: it means the crack was a symptom, not the problem. Repeated cracking in the same region of an aluminum fishing boat usually indicates flexing from a loose or failed structural member — a cracked stringer, a delaminated transom, missing or broken rivets in a riveted hull, or a trailer with bunks positioned so the hull is unsupported and pounding on every bump. Weld it and it will crack again next season. Fix the trailer bunk alignment and inspect the stringers before you blame the weld.

Warping into a hook or rocker on the bottom panel changes how the boat runs and cannot be un-welded. This is why heat control is not a cosmetic concern — a heat-distorted bottom panel forward of the transom can make a boat porpoise or chine-walk. Prevention is the only cure: stitch, cool, clamp, and use a backing bar.

Whitish powder around the repair after a season is aluminum oxide from galvanic activity. Check anodes, check for a stray-current source at the dock, and check that you did not leave a steel wire brush's worth of iron in the weld.

Finally, know when to stop. If the second attempt at a repair leaks, or the crack reappears, or you have punched a hole while chasing burn-through, put the grinder down and take it to a shop. There is no prize for a hull that leaks slowly.

Related questions

Can you weld an aluminum boat with the fuel tank still in it?

No. Drain the tank, remove it if it is portable, and ventilate the compartment before any hot work. Vapor, not liquid fuel, is what ignites. This applies even to a tank on the opposite end of the boat.

Do I need to remove flotation foam before welding?

Yes, within roughly 6–12 inches of the weld zone. Closed-cell foam melts and can smolder inside a sealed compartment where you cannot see or reach it. Cut an access panel, pull the foam, weld, then replace with new pour-in or block foam.

Will welding void my hull warranty?

On a boat still under manufacturer warranty, almost certainly yes for the affected area. If the hull is under warranty, call the manufacturer first — many cover hull cracks as a defect, and an owner-performed weld forfeits that.

Is 5356 or 4043 filler better for a hull repair?

5356 for 5xxx marine hull plate — stronger and far better in salt water. 4043 when a 6061 extrusion is on one side of the joint, since it resists cracking there. Do not use 4043 on 5083/5086 in salt.

How thin is too thin to weld?

Below roughly 0.063" most hobbyists cannot avoid burn-through. At 0.063"–0.080" it is possible with AC TIG, a backing bar, and pulsing, but a bonded or riveted patch plate is often the more reliable owner-level answer.

FAQ

How long does a basic aluminum hull weld repair take?

For a 3–4 inch non-structural crack: plan a half day. Cleaning, stripping, degreasing, and dye-penetrant work take 45 minutes to an hour. Stop-drilling and beveling take five to ten minutes. The actual stitch welding takes twenty to thirty minutes because most of it is waiting for the panel to cool. Grinding, testing, priming, and painting take another hour. Your first one will take longer than that; your fifth will take under two hours.

Can I weld the hull with the boat on the trailer?

Usually yes for side panels and gunwale areas, provided the seam is accessible and you can get a ground clamp on clean bare metal near the work. Disconnect the trailer from the tow vehicle and disconnect the trailer wiring — welding current will happily find a path through trailer lights and cook them. For bottom-panel work you need the hull blocked or on stands where you can reach both sides. Never weld on a hull that is sitting on a trailer's rollers, where the panel is unsupported and will distort.

What gas do I use, and how much?

Pure argon, 100%, at roughly 20–30 CFH depending on cup size and how much wind you are fighting. Do not use an argon/CO2 mix — the CO2 will contaminate the weld badly on aluminum. Helium or argon/helium blends run hotter and are useful on thick plate, but on 0.125" hull plate they will make burn-through more likely, not less.

Do I need to weld both sides of the crack?

On plate under about 0.125", a properly beveled and fully penetrated single-side weld is enough. Over that, a root pass on one side and a back weld on the other gives a much more reliable joint — but that requires access to both faces, which is exactly the access question that pushes some repairs to the shop.

How do I know the repair is actually watertight?

Two tests, both cheap. Dye penetrant on the cleaned bead reveals surface-breaking porosity and cracks. Then a leak test: a few inches of standing water inside the compartment, watched from outside for fifteen minutes, or soapy water outside with very low-pressure air inside. Then sea-trial it at speed and re-inspect — flex under load finds what static testing misses.

Should I paint over the weld?

Yes, after it is fully clean and dry. Bare aluminum in salt water pits, and the heat-affected zone around a weld is chemically the most vulnerable part of the panel. Use a self-etching aluminum primer followed by a marine topcoat, and while you are at it verify your sacrificial anodes are intact — a fresh bare weld plus a depleted anode is an accelerated corrosion setup.
